HVP30 HVP40 series vane pump

HVP30 HVP40 series vane pump HVP30 HVP40 series vane pump HVP30 HVP40 series vane pump

Product name:HVP30 HVP40 series vane pump

Item:

Details:

HVP30 HVP40 series vane pump

Quick Details

Type:

HVP30 medium pressure hydraulic pump

Model Number:

HVP30

Brand Name:

ZF HYDRAULIC

Placeof Origin:

China(Mainland)

pressure range:

70--140bar (kgf/cm2)

displacement:

30L/min

shaftkey:

parallelkey

shaftdiameter:

19.05mm

flangesize::

95.02mm

parallelkey spec.:

25mmlength, 4.76mm width

sauctionport diameter:

3/4 "

deliveryport diameter:

1/2"

drainport diameter:

1/4"

weight:

9.55kg



Supply Ability

SupplyAbility:

10000Piece/Pieces per Month

Packaging & Delivery

PackagingDetails

plasticbag pack pumps,then put into thick carton, then heap up these cartons on theplastic pallet.

Port

SHENZHEN







Product Description

HVP30high pressure hydraulic pump




Packaging & Shipping

Packaging:pack one pump in one plastic bag,then put it in one thick paper carton,thenheap up them on the plastic pallet, wrap the plastic pallet andcartons with plastic membrane then bind the cartons with plasticpacking belt.

Deliverydate:about 10-20 days after receipt your 30%T/T for deposit

Tradeterm: FOB SHENZHEN,or FCA or C&F or CIF


Shippingfor sample and bulk productions:

sendsample by international Express(Fedex or UPS or TNT or DHL),sample freight paidby collect.

Forbulk production, shipped as per customer's instruction,shipping process allfllow INCOTERM regulations.

Productpacking details:

style#

carton dimension of each item

net weight

gross weight

quantity

HVP40

TBA

10 kg

11 kg

1 pc/ carton


Our Services

Warrantyperiod:  ONE YEAR



1,Withinone week after receipt of the goods, if customer use the products in correctmethod,and find any problem of performance or  construction with obviousevidence,we will be responsible for replacement or other discussing solutionbetween us.

2,Butif customer using method are not correct, or customer disassemble our productsprivately,we will not  responsible  for any problem or defectivepoints of products.

3,If you meet any questions of installation or debugging, please inquiry usanytime, our Engineer will provide technical support in time, or we will helpyou to resolve the technical failure through online video.

4,Any damage from transportion, we will slove the problem according to theresponsibility standard of INCOTERMS.
